Ohlins Street S46 Shock: KTM Duke 790

Ohlins Street S46 Shock: KTM Duke 790

The STX46 Street Performance Line is based on our popular STX46 DR1 shock absorber and developed for naked sports bikes and street performance bikes. It features a large 46mm main piston and an internal gas reservoir within the main body of the shock.

With adjustable damping you can change the behavior of the shock to suit your taste and even fit a hydraulic spring pre loader to change the stance of the bike. This is the perfect choice for the naked sports bike, or as well call it: Street Performance Line.

Specs
Monotube shock absorber

Öhlins well proven design

Adjustable rebound damping and compression

A range of spring rates available

Maintenance possibilities

Optional hydraulic spring pre loader

Available to a large range of bike models

Type S46HR1C1B

Single Tube Design

46mm piston diameter

Monotube high pressure gas type of shock absorber with hose mounted reservoir

Adjustable rebound damping Adjuster wheel or slot above the eye end or on the reservoir

Adjustable compression dampening. Adjuster wheel or slot on the reservoir

Integrated hydraulic spring preload adjuster. Adjuster wheel or hexagon on the adjuster


All Öhlins shocks are supplied based on rider's weight
